| No. | Category | Detailed Specifications |
|---|---|---|
| Vehicle Parameters | ||
| 1 | Vehicle Model | ESH5310GGJB |
| 3 | Drive Type | 8*4 |
| 4 | Wheelbase (mm) | 1850+3200+1350 |
| 6 | Curb Weight (kg) | 15500 |
| 7 | Rated Loading Mass (kg) | 15500 |
| 8 | Max Total Mass (kg) | 31000 |
| 9 | Max Speed (km/h) | 90 |
| Engine & Transmission | ||
| 11-12 | Engine Model | Sinotruk 385N CNG full power power take-off |
| 13 | Displacement (L) | 6.87 |
| 14 | Power/Speed | 283KW / 2300rpm |
| 15 | Emission Standard | Euro 5 |
| 17 | Transmission | Fast Ten Gear 12JSD180AT |
| Chassis & Braking | ||
| 19-20 | Axle Models | Front: 30Z01-00005 / Rear: 24BB-00005 |
| 21-22 | Suspension | Vertical leaf springs (Front 9pcs / Rear 13pcs) |
| 23-24 | Frame | Outer width 860mm / Stringer section 388(8+8) |
| 25-27 | Brake System | Double circuit pneumatic drum / Spring air brake |
| 30 | Tires | 13/12.00R20 18PR |
| Body & Comfort | ||
| 31 | Basic Config | Air conditioner, electric cab lift, electric window/mirror, 840L total gas capacity |
| 32 | Carriage Specs | 6500*2350*1500mm (Side 8mm, Bottom 10mm) |
